General Motors GM-50649 Front Output Shaft Seal Installer
General Motors GM-50649 Front Output Shaft Seal Installer
Kent-Moore Tool Number: DT-50649
A new design two-piece front output shaft seal and new slinger (dust shield) have been introduced for heavy duty and super heavy duty (Magna NQF / NQG) transfer cases. The new design seal has a different installation depth (for inner portion of the seal) than do the previous New Venture Gear transfer case applications. The previous seal was installed with the inner portion of the seal below flush, using GM-43484. The new design seal must be installed with both portions of the seal installed flush to prevent seal damage. The new seal and slinger will be implemented to back service for all Magna transfer cases (RPOs-NQF / NQG / NQH / NP0) back to 2007MY, and is planned for use on all future light duty and heavy duty applications. GM-50649 installs the seal correctly, and also installs the new slinger onto the output shaft. GM-50649 is anodized blue to differentiate it from GM-43484, which is natural aluminum in color.
For the General Motors Tools Catalog, click here
Looking for General Motors Specialty Tools?
Rest assured, we're here to guide you. If you can't find the GM car repair tools you're looking for in our catalog, please don't hesitate to contact us. Our dedicated and knowledgeable team is ready to assist with any inquiries and help you find the right tool to meet your needs. You can reach us directly at (909) 334-4400. Tillman carries the broadest online inventory of automotive tools.
Wide Selection of Tools:
Do you need hard-to-find quality mechanic tools, high-end electrician tools, auto body repair tools and supplies, or forestry tools at affordable prices? Look no further! With FREE shipping on selected items, our store has everything you need. Whether you're an authorized repair shop, an independent repair shop, or a DIY enthusiast needing specialty automotive tools, hand tools, or equipment, we have you covered. Our selection includes parts and specialty tools for Harley-Davidson, Ducati, and Suzuki, ensuring the job is done correctly.
Original: $156.99
-65%$156.99
$54.95Product Information
Product Information
Shipping & Returns
Shipping & Returns
Description
General Motors GM-50649 Front Output Shaft Seal Installer
Kent-Moore Tool Number: DT-50649
A new design two-piece front output shaft seal and new slinger (dust shield) have been introduced for heavy duty and super heavy duty (Magna NQF / NQG) transfer cases. The new design seal has a different installation depth (for inner portion of the seal) than do the previous New Venture Gear transfer case applications. The previous seal was installed with the inner portion of the seal below flush, using GM-43484. The new design seal must be installed with both portions of the seal installed flush to prevent seal damage. The new seal and slinger will be implemented to back service for all Magna transfer cases (RPOs-NQF / NQG / NQH / NP0) back to 2007MY, and is planned for use on all future light duty and heavy duty applications. GM-50649 installs the seal correctly, and also installs the new slinger onto the output shaft. GM-50649 is anodized blue to differentiate it from GM-43484, which is natural aluminum in color.
